Electric Dirt Motorcycle

ROI Tuktuks EV Motorcycles, the electric iteration of the iconic three-wheeled "Tuktuk" vehicles widely recognized in Southeast Asia, South Asia, and other regions, have emerged as a game-changer in urban and rural mobility. Originating from the traditional fuel-powered Tuktuks—loved for their agility, affordability, and ability to navigate congested streets—the electric version inherits these core advantages while integrating eco-friendly propulsion systems. As the global drive for carbon neutrality intensifies, TUKTUK EV Motorcycles are gaining traction as a sustainable transportation solution, catering to the daily commuting, tourist shuttle, and light cargo delivery needs of local communities and businesses.



产品参数
  • 支付 :

    T/T
  • 产品产地 :

    China
  • 交货时间 :

    60 days



Distinguished by their unique three-wheeled structure—typically with one front wheel and two rear wheels—TUKTUK EV Motorcycles are designed for optimal maneuverability in narrow lanes and heavy traffic, a key advantage over traditional four-wheeled vehicles in densely populated areas. Unlike their fuel-powered predecessors that emit exhaust fumes and produce loud "tuk-tuk" engine noises, these electric models are powered by high-efficiency Brushless DC (BLDC) motors. This motor type eliminates the need for brushes and commutators, resulting in quieter operation, lower maintenance costs, and higher energy conversion efficiency—critical for extending the vehicle's range with limited battery capacity.



Features
Production base OEM
Model Name DUDU
L×W×H(mm) 2750×1350×1830
Wheel base(mm) 2050
Wheel track(mm) 1150
Minumum ground clearance mm ≥210
Minimum turning radius m ≤4.35
Curb weight(kg) 350No including battery
Battery weight: 100kg
Max speed km/h 50
Max slope of climb% ≤25
Battery LFP76.8V125Ah=9600W
Motor, Electric power controlw Rated power: 72V3000W
Peak power: 4500W
Driving mileage at efficient speed km 150
Charging time h 6h
loading capacity 1 driver+3 passengers
Front shock absorber Twin shock absorberwith spring
Rear shock absorber Independent trailing armwith helical spring
Front/Rear tyre 4.00-12
Rim type steel
Handlebar type
Steering wheel type -
Front/Rear brake type Oil drum brake
Paking brake footbrake









 Three Rows Tricycle
Dimension(L*W*H) 3300mmx1250mmx1790mm(including bumper)
Vehicle weight 320 kg (Battery not included)
Wheelbase 2270mm
Tread 1000mm
Minimum ground clearance 280mm
Loading Capacity 800kg
Passenger Capacity 7 people
Speed Maximuim 50km/h
Motor power 3000w
Lamps Headlight+Turn Signal+Driving Light+Reversing
Light
Workbench & instrument Dedicated
Wiper Motor Pure copper motor
Tire size Front wheel 400-12, Back wheel 400-12
Wheels slron wheels (galvanizated)
Electronic Control System 36-tube intelligent dual-mode controller
Controlling Method Twist-handle
Driving Method Direction handle
Braking Method Mechanical drum brake
Wiring Arrangement of Assembly Wiring Hamess High and low voltage dual lines: high temperature
line high voltage16mm² low voltage 1.5mm²
Front shock absorber Direct plug hydraulic shock absorber
Drive axle 220 drum brake integrated rear axle
Rear Suspension Support arm spring structure
Tarpaulin Composite oil canvas (off white)
Frame material One-piece curved beam structure, the main beam
adopts 40mm*60mm*4mm rectangular tube, the
secondary beam adopts 40mm*60mm*3mm
rectangular tube and is treated with cathodic
electrophoresis for corrosion and rust prevention.
Carriage structure The front and rear panels are integrally stamped
and detachable,making assembly simple and
convenient



Type Display
  • #

  • #

  • #

Motor 48V/5KW Net weight 1069.5lb
Battery 48V150 AH lithium iron phosphate Seating capacity 2 people
Charger Vehicle mounted intelligent Forward speed 21.74 km/h
Tire Size 10 inch Braking dist ≤196 inch
Dimension 107*47.2*78.7 inch Turning radius ≤146.7 inch
Ground clearance 4.3 inch Climbing ability 20%
Tread distance front: 66.9 inch rear; 39.3 inch Maximum
mileage
49.7 mi






Motor 48V/5KW Net weight 1114lb
Battery 48V150 AH ithium iron phosphate Seating capacity 4 people
Charger Vehicle moumned intelligent Forward speed 24.85 km/h
Tire Size 14 inch Braking dist ≤196 inch
Dimension 119*52*82.6 inch Turning radius ≤146.7 inch
Ground clearance 4.3 inch Climbing ability 30%
Tread distance front: 66.9 inch rear; 39.3 inch Maximum mileage 68 mi





Motor 72V/6.3KW Net weight 2620 Pourd
Battery 200AH Seating capacity 14 people
Charger Vehicle mounted intelligent charger Forward speed 17mi/h
Tire Size 12/14 inch Braking dist ≤236 inch
Dimension 207*56*76 inch Turning radius 200 inch
Ground clearance 5.9/6.5 inch Climbing ability 20%
Tread distance front: 35.4 inch rear; 39.4 inch Maximum mileage 50 mi





Motor 48V/3KW 60V/4KW Net weight 1650 Pourd
Battery 150AH Seating capacity 8 people
Charger Vehicle mounted intelligent charger Forward speed 17mi/h
Tire Size 10 inch Braking dist ≤236 inch
Dimension 151*48*74 inch Turning radius 200 inch
Ground clearance 4.3 inch Climbing ability 20%
Tread distance front: 35.4 inch rear; 39.4 inch Maximum mileage 38-50 mi





In conclusion, Tuktuks are more than just vehicles—they are a cultural icon that embodies the energy, warmth, and adaptability of the regions they call home. Whether you’re a traveler looking for an authentic way to explore a new place or a local going about your daily life, a ride in a Tuktuk is an experience that’s hard to forget. It’s a reminder that sometimes the best way to see a place is slow down, feel the wind in your hair, and let the rhythm of the street guide you.
